Features:
.:
High Speed Wipe Operation: Data Sanitizing speeds can exceed 3GB/min.
.: Sanitize Multiple Drives Simultaneously:
Sanitize up to 9 drives simultaneously.
.: Multiple Media Support: Supports P-ATA and
S-ATA hard disk drives. Notebook drives and ATA compatible
Flash devices are supported using ICS proprietary adapters.
.: Multiple Sanitizing Modes: The WipeMASSter
can erase data on drives in one pass or by following the strict
DoD (Department of Defense) standard which requires seven
passes.
.: Partitions and Formats Drives: Drives can be
automatically partitioned and formatted with the optional Format
Add-On Option, eliminating the need to manually prepare a drive
prior to usage.
.: Sanitize Different Drive Models and Sizes:
Simultaneously erase data using different drive models and
sizes.
.: 48-Bit Support: Provides 48-bit drive
support to handle hard drives larger than 137GB.
.: DCO and HPA: Provides the ability to
erase hidden areas on hard-drives.
.: Multiple User Defined Settings: This feature
allows authorized users to store multiple user defined unit
settings.
.: Password Protected Settings: This feature
protects the unit’s user defined settings from being changed
by un-authorized users.
.: Log Information: Detail operational event
log information can be viewed or saved to Compact Flash.
.: Upgradeable: Software upgrades can be easily
performed using the unit’s supplied Compact Flash Card.
.: eSATA:
Supports eSATA drives with the purchase of a SATA-to-eSATA data
cable
-----------------------------------------------------------------------------------------------------------------
Software
:
The
following Software features come standard with the IM
WipeMASSter unit:
.: HPA Option: The WipeMASSter unit supports
sanitizing HPA areas. HPA is defined as a reserved area
for data storage outside the normal operating file system.
If an HPA area exists on a drive the WipeMASSter will clear and
erase the HPA area.
.: DCO Option: The WipeMASSter unit supports
sanitizing DCO areas. DCO allows systems to modify the
apparent features provided by a hard disk drive. If DCO is
detected on the drive, the WipeMASSter will clear and erase the
DCO area.
.: WipeOut DoD: This function is designed to
erase all data on disk drives. Sanitize up to 9 drives
simultaneously at speeds greater than 3GB/min. WipeOut was
designed to meet the U.S. Department of Defense specification
DOD 5220-22M regarding the sanitization of hard disk drive data.
Each iteration makes two write passes over the entire drive.
.: WipeOut Fast Option: The Wipeout Fast option
provides a quick non-DoD method of sanitizing a drive of all
previously stored data. Allows erasing data in one pass.
.: Store Log and Database Information: The unit
provides functions to display and store real time event
information in a log and database format.
.: Manage User Defined Settings: This built in
feature allows authorized users to store multiple user defined
unit settings.
-----------------------------------------------------------------------------------------------------------------
Optional
Hardware
.: FORMAT
FAT32: The FORMAT FAT32 Option provides the capability
of performing a quick FAT32 format on multiple drives.
The operation creates a non-active FAT32 primary DOS partition
on the drive(s) connected.
-----------------------------------------------------------------------------------------------------------------
Specifications
.:
Serial-ATA
Adapters:
Single Channel and Multi-Channel S-ATA adapters are available to
support sanitizing S-ATA drives. The S-ATA 9-Channel
adapter coverts all ports of the WipeMASSter for S-ATA usage.
The Single Channel S-ATA adapters allow mixing P-ATA and S-ATA
drives.
.: Notebook
Adapters: ICS proprietary Notebook Adapters
enables the WipeMASSter to support a variety of Notebook models
that use a proprietary Notebook drive interface. Adapters
available include adapters for the IBM Think-Pad, Compaq Armada,
NEC Versa, Dell Latitude, and Toshiba Tecra. The ICS
Standard 2.5” adapter supports all Notebook drives which do
not have a proprietary interface or have been removed from their
proprietary enclosures. An ICS proprietary adapter is also
available for the 1.8” ATA drive interface.
.: Flash
Adapter:
The Flash adapter was designed to support 50-pin micro-drive
devices.
.: AShelf
Solution:
This Shelf Solution provides the WipeMASSter user with an
alternative method to mount nine drives to the unit. The
standard tray format requires the drives to be mounted
vertically, while the Shelf Solution allows the drives to be
mounted in the traditional horizontal position.
.:
Drive Cooler Solution:
Reduces the heat generated by the hard drives and maintain a
comfortable operating temperature.
.:
Micro
S-ATA 3.3V, 1.8" adapter: The
Micro S-ATA 3.3V adapter can be used to convert from the
standard 5V S-ATA 22-pin interface to the 3.3v Micro S-ATA
16-pin interface used by Micro S-ATA drives.
.: eSATA: Supports eSATA drives with the purchase of a
SATA-to-eSATA data cable
.:
Supply Voltage: 100
- 240V / 50 - 60 Hz
.: Power Consumption: 10W without drives
.: Operating Temperature: 5 degrees - 55
degrees C
.: Relative Humidity: 20% - 60% non-condensing
.: Net Weight: 9 lbs
.: Overall Dimensions: 13.3” x 12.1” x
4.4”
.: Universal Auto-Switching input voltage
|
