Since some hard drives, when attached to the SDL, will not be recognized when connected to native SATA ports on some PC’s, ICS recommends the use of the E-SATA controller card to ensure 100% compatibility with both the PC and the drive connected to the SDL

Features

.: Multi Media Write-Protect Support: Built-in USB 2.0, P-ATA, S-ATA and SCSI interfaces provide native write protect support for USB, P-ATA, S-ATA, and SCSI devices. Supports SCSI interfaces such as Ultra-160 and Ultra-320, including SCSI Narrow (50-pin), SCSI Wide (68-pin) and SCSI-SCA80 (80-pin). Supports 3.3v devices.

.: High Speed Operation: Transfer rates can exceed 3.5GB/min

.: Multiple O/S Host Support: Supports Windows XP, Windows VISTA and Linux.

.: Upgradeable Firmware: The unit's firmware can be easily upgraded using the PC's interface.

.: Multiple Host Interface Support: Unit can be connected to the PC or Notebook using multiple interfaces such as native S-ATA port, eSATA controllers, eSATA CardBus adapters.

.: Portable: Can be used as a portable device or mounted in a PC available drive bay.

.: HPA/DCO Support: Detects HPA and DCO areas

.: 3.3v Device Support: Provides output for devices which require 3.3v for operation.

.: Status leds: 4 leds; IDE drive detected, SATA drive detected, SCSI drive detected, USB device detected

Optional Hardware

.: eSATA PCI Controller Card: Provides a “hot swap” eSATA interface to connect the Super DriveLock with the PC.  Installs in a PC’s available PCI Slot.
.: eSATA PCI-EXP Controller Card:Provides a “hot swap” eSATA interface to connect the Super DriveLock with the PC.  Installs in a PC’s available Express Slot.
.: Power Supply + USB to SATA Adapters:The Power Supply provides external power for the Super DriveLock device, allowing the SDL to be used as a portable device. The USB to SATA adpater can used to connect the SDL to the PC or Notebook using the USB interface.
.: Super DriveLock Hard Case:Provides a portable carry case for the Super DriveLock device.
.: In-Bay Drive Tray & Cooling Fans: Designed for the use with the Super DriveLock and Super DrivePort when the devices are mounted in an available PC drive bay. Cooling fans are provided to keep the drives cool.

Specification

Super DriveLock  Basic Kit:

Each Basic Unit Kit includes:

(1) Super DriveLock Unit
(1) External USB Device Data Cable
(1) S-ATA Data/Power Cable
(1) 8" P-ATA /SCSI Power Cable
(1) 6" S-ATA 3.3v/5v Power Cable
(1) 6" S-ATA Data Cable
(1) 6" SCSI Data Cable
(1) SCSI Terminator
(1) 5" P-ATA Data Cable
(1) eSATA to S-ATA Data Cable
(1) USB A to A F/W Upgrade Data Cable
(1) eSATA to eSATA Data Cable
(1) 36" P-ATA/SCSI Power Cable
(1) SCSI Narrow Adapter
(1) SCSI SCA80 Adapter
(1) 18" P-ATA Data Cable
Warranty Documents

Super DriveLock Unit's specifications:

.: Maximum Possible Power: 9 watts typical operating ( not including hard disk)
.: Stand by Power: 5 watts
.: Supply Voltage (DC IN): +VDC @ 2A, +12VDC @ 2A ( includes budget for hard disk)
.: Output voltage (DC OUT): +5VCD @ 1A, +12VDC @ 1A
.: Dimensions: 5.75 in. (L) x 3.25 in. (W) x 1.125 in. (H)
.: Weight: 1 lb
.: Operating temperature range: 0 to 55 degrees C (no air flow)
.: Storage temperature range: -40 to 70 degrees C
.: Relative humidity: Up to 90% (non condensing)
